This product is manufactured and designed to be compatible or used with appliances, or for selected commercial/domestic applications.

• 868 Mhz Radio frequency programmable thermostat
• Equipped for wall mounting or table-top use
• Volt-free switching suitable for combination boilers
• Boiler Plus Compatible

This is a high quality compatible, alternative product. It is designed to provide you with an alternative working solution to the genuine original equivalent. This alternative choice is reflected in all our compatible parts and accessories offering you a cost saving against the original product. All manufacturers’ names and numbers used for reference purposes only.

Universal products can be used for many makes and models of machine providing it matches the product type and specification. We stock and supply a wide range of universal spare parts, consumables and accessories.

The optimum vibe is a radio frequency battery-powered programmable room thermostat with touch-screen controls, providing six timed temperature periods every 24 hours. The transmitter (Tx) has a large blue backlit display and runs a pre-programmed user adjustable temperature profile. Users can just touch the up or down control icon at any time to manually adjust the current temperature setting.

The receiver (Rx) must be wall-mounted adjacent to the boiler, provides volt-free switching and displays indicator l.e.d. showing power and load status, and has a button for manual operation if required. The control set uses the license-free 868mhz frequency, and is pre-linked in the factory with a unique code.

• DIMENSIONS Tx: 120 X 85 X 22.5 Rx: 85 x 85 x 25
• Rx CONNECTIONS: 5 X WIRE-PROTECT CAGE SCREW TERMINALS
• RESISTIVE LOAD: 10 AMPERES RESISTIVE @ 230V 50Hz
• POWER SUPPLY Tx: 2 x AAA ALKALINE Rx: 230V 50Hz
• TEMPERATURE RANGE: 5-30°C
• FROST PROTECTION: SET TO OFF, OR USER ADJUSTABLE 5 – 15°C
• TEMPERATURE REGULATION: SELECTABLE: ON/OFF ~ OPTIMISING ~ T.P.I.
• DIFFERENTIAL: +/- 0.5°C
• TIMING ACCURACY: (typically +/- 2.5 sec / day)
• PROGRAMME CAPACITY: 6 x USER ADJUSTABLE TEMPERATURE PERIODS
• DAY GROUPS: 5 & 2: (WEEKDAY / WEEKEND) or 7: INDIVIDUAL DAY PROGRAMMING
• ADJUSTABLE SETTINGS: 5 TEMPERATURE LEVELS: MEASURED, MAXIMUM, MINIMUM, DIFFERENTIAL, FROST PROTECTION. BACKLIGHT AUTO or OFF. DAY SELECTION 5&2 or 7. TEMPERATURE

REGULATION MODE:

• ON/OFF ~ OPTIMISING ~ T.P.I.
